الوصف
المميزات
- LowPulseStrTM SpO2 algorithm more reliable readings of SpO2 during low perfusion and
- iFastBP® NIBP algorithm used for fast and comfortable
- wSmartHeart® ECG technology for more safe monitoring of
- iRealRespTMBreating rate technology to get the real reading during
- wSmartGas® Capnograph technology to get reliable reading during multi-environment.
- Multi display mode Big
- 8 inch screen can be optional.
- Wi-Fi connectivity more flexible
- eTeleViewTMCentral Montior system
- Smart alarm system more safety and more efficient
- Fanless design
- Compact design and easy to
|
|
VS800 |
|
| Standard application | SpO2 | PR |
| NIBP | TEMP | |
| Optional application |
Wi-Fi |
Printer |
| 3 Leads ECG | Touch Screen | |
| 5 Leads ECG | Infrared thermometer (Wired) | |
| EtCO2 (Mainstream, TiniStream) | Infrared thermometer (Wireless by Bluetooth) |
CENTRAL MONITORING SYSTEM:
- Central Monitoring System supports up to 64 beds or 64 patients across clinical units at the same time. 240 hours of 64-channel holographic physiological waveform storage and review.
- Provides review of up to 240 hours trend data storage, 720 alarm events per beds.
- Bi-directional communication with VS800 Series monitors for enhanced patient care.
PARAMETERS
TEMP
…………………………………………………………………………………………………….
Range: 0-50°C Accuracy: ±0.1°C Resolution: 0.1°C
PR
…………………………………………………………………………………….
Range: 25~300bpm Accuracy: ±3bpm Resolution: 1bpm
SpO2
……………………………………………………………………………………………………………………………………………………………………………………………………
SpO2 Range: 0~100%
SpO2 Accuracy: 70~100%, ±2% <70%, Undefined PI Range: 0~20%
PVI Range: 0.001%
NIBP
……………………………………………………………………………………………………………………………………………………………………………………………………
Pressure Range: 0~300mmHg
Pressure Accuracy: ±2mmHg or ±1% of reading(take the larger value) Resolution: 1mmHg
SYS Range: Adult: 40-270mmHg Pediatric: 40-235mmHg Neonate: 25-130mmHg DIA Range: Adult: 10-210mmHg Pediatric: 10-200mmHg Neonate: 10-90mmHg Mean Range: Adult: 20-230mmHg Pediatric: 20-225mmHg Neonate: 15-100mmHg Accuracy: The mean deviation<±5mmHg The standard deviation<8mmHg
ECG(Optional)
……………………………………………………………………………………………………………………………………………………………………………………………………
ECG Range: 0.15~5.5mV ECG Resolution: 2.36uV/LSB
HR Range: 15~300bpm(adult) 15~350bpm(child/neonate) HR Accuracy: ±1bpm or ±1%(whichone is greater)
RR Range: Adult: 0~120rpm; Pediatric, Neonate: 0~150rpm RR Accuracy: 15~150rpm: ±2rpm or ±2% <15rpm: Undefined
EtCO (Optional)
……………………………………………………………………………………………………………………………………………………………………………………………………
CO2 Range: 0~20.0vol%
CO2 Accuracy: 0~12vol%: ±(0.2vol%+2%of reading) 12~20vol%: ±(0.2vol%+6%of reading)
AwRR Range: 0~150rpm
AwRR Accuracy: mainstream: 0~150rpm, ±1rpm Side stream: 0~70rpm, ±1rpm 71~150rpm, Undefined
PATENT
SpO2
Patent No: ZL 2019 1 0907433.8
ZL 2019 2 1510989.5
ZL 2019 2 1596814.0
تخطيط القلب
Patent No: ZL 2015 0484280.2
ZL 2019 1 0064711.8
ZL 2017 1 0691935.2
ZL 2021 2 0480587.6
EtCO2
Patent No: ZL 2018 1 0713045.1 ZL 2018 1 0713152.4
ZL 2020 2 1177039.8 ZL 2019 2 0722093.7
ZL 2017 2 0804416.8 ZL 2017 2 0293754.X
